Now you have two different electrical devices operating at different voltage levels.

Consider a microcontroller-based project where you want to control a 220-volt lamp with ESP32.

For further information, check examples that are given in the next section. In short, 4N25 optocoupler is used in applications where to want to isolate electrical circuits from each other. In other words, it is used to make an electrical connection between two electrical circuits through photonics signals such as infrared LED and phototransistor. The phototransistor turns on and turns off according to a state of the logic switch.Īs their name suggests, 4N25 and other equivalent optocouplers such as 4N26, 4N27, 4N28 can be used to provide electrical isolation between two circuits. At the input side, the logic signal probe provides a logic high-low signal to a photodiode. This circuit demonstrates LED controlling with a switch optically.

This animation depicts a simple example of an optocoupler of any type. No external biasing power supply required to power IC.It is tested up to 5000 Vrms isolation voltage.Collector-Emitter voltage breakdown is 70V.The power dissipation of the infrared photodiode is 100mW.Input side reverse voltage is 5 volts and forward current is 60mA.Coupling capacitance between the input and output side is less than 0.5 pF.4N25 optoisolator has very fast switching time.Offer high voltage isolation of 500Vrms test voltage.4N25 Features and Electrical Specifications
